GaAs INTEGRATED CIRCUIT

? PG2183T6C

4 W HIGH POWER SP4T SWITCH

DESCRIPTION

The ? PG2183T6C is a GaAs MMIC SP4T (Single Pole Four Throw) switch which was designed for digital cellular

phone application.

This device can operate frequency from 0.5 to 2.5 GHz, having the low insertion loss and high isolation.

This device is housed in a 16-pin plastic QFN (Quad Flat Non-leaded) (T6C) package. And this package is able

to high-density surface mounting.

FEATURES

? Supply voltage

? Standby mode voltage

: V bat = 2.9 to 3.2 V (3.0 V TYP.)

: V DD (H) = 1.7 to V bat V (2.65 V TYP.)

: V DD (L) = 0 to +0.05 V (0 V TYP.)

Switch control voltage

Operating Frequency

Low insertion loss

High isolation

Handling power

: V cont (H) = 1.7 to V bat V (2.65 V TYP.)

: V cont (L) = 0 to +0.05 V (0 V TYP.)

: f = 0.5 to 2.5 GHz

: L ins 1 = 0.4 dB TYP. @ f = 0.5 to 1.0 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: L ins 2 = 0.55 dB TYP. @ f = 1.0 to 2.0 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: L ins 3 = 0.7 dB TYP. @ f = 2.0 to 2.5 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: ISL1 = 24 dB TYP. @ f = 0.5 to 1.0 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: ISL2 = 19 dB TYP. @ f = 1.0 to 2.0 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: ISL3 = 17 dB TYP. @ f = 2.0 to 2.5 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: P in (0.1 dB) = +37.5 dBm TYP. @ f = 0.9 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

: P in (0.1 dB) = +35.0 dBm TYP. @ f = 1.8 GHz, V bat = 3.0 V, V DD = V cont (H) = 2.65 V, V cont (L) = 0 V

High-density surface mounting : 16-pin plastic QFN (T6C) package (3.0 ? 3.0 ? 0.75 mm)

APPLICATIONS

? Digital cellular phone etc.

ORDERING INFORMATION

Part Number

Order Number

Package

Marking

Supplying Form

? PG2183T6C-E2 ? PG2183T6C-E2-A 16-pin plastic QFN

(T6C) (Pb-Free)

2183

? Embossed tape 12 mm wide

? Pin 13, 14, 15 and 16 face the perforation side of the tape

? Qty 3 kpcs/reel

Remark To order evaluation samples, please contact your nearby sales office.

Part number for sample order: ? PG2183T6C-A

Caution Although this device is designed to be as robust as possible, ESD (Electrostatic

Discharge) can damage this device. This device must be protected at all times from ESD. Static

charges may easily produce potentials of several kilovolts on the human body or equipment, which

can discharge without detection. Industry-standard ESD precautions must be employed at all times.

Document No. PG10762EJ01V0DS (1st edition)

Date Published May 2009 NS
